3.5/7kW Portable AC Charging Station
· Housing material: Thermoplastic,flame retardant grade UL94 V-0
· Terminal: Copper alloy,silver plated on the surface
· Working environment temperature: -20℃ ~+50℃
· Rated working current: 16A/32A
· Working voltage: 250V
· Insulation resistance: >1000MΩ(DC500V)
Detail
Product Parameter
| Product Name | Portable AC Charging Box (Plastic Type) | |
| Model | AF-AC-3.5kW | AF-AC-7kW |
| Overall dimensions (mm) | / | |
| Human-computer interaction | LED indicator strip | |
| AC power supply | 220Vac±20%;50±10 Hz | |
| Rated input and output current | 16A 32A | |
| Rated output power | 3.5kW 7kW | |
| Working enviroment | Altitude : 2000m; Temperature: -20°C~+50 °C | |
| Charging method | Plug and charge | |
| Networking methods | / | |
| Operation mode | / | |
| Executive standard | IEC 62752 :2016 | |
| Charging cable length | Standard 5 meters(optional) | |
| Protection g「ade | IC-CPD IP67,Vehicle Connector IP54 | |
| Protection function | Overvoltage protection, undervoltage protection, overload protection, grounding protection, overcurrent protection, leakage protection, over temperature protection | |
